Battery Spot Welder and Soldering Station Portable Pulse Welding Machine for Battery Pack 18650 14500 Lithium Batteries, for Batteries 18650 Packs Spot Welding Equipment

Handheld Battery Spot Welding MachineFeatures:Fixed pulse spot welding can realize precise fixed welding.The welding needle pressure regulator is convenient for welding workpieces of different thicknesses, so as to obtain good and reliable welding points.The compact body shape, small and portable, combined with a convenient handle, makes it light and easy to move.Wide range of applications, suitable for various sizes of battery packs, button batteries, polymer batteries and protective plates, mobile phone cameras, stainless steel hardware, stainless steel mesh, etc.Specification:Power supply voltage: AC220V/110V±20VPower: 4.3KWWelding current: 120---1200A4 Pulse time: 1 ms-10 ms (adjustment)6 Pulse time: 2 ms-20 ms (adjustment)8 pulse time: 8 ms-80 ms (adjustment)Fixed head spot welding range: 0.15~0.35mmSpot welding range of spot welding pen: 0.05~0.25mmOutput voltage: 20V DCBody: 140×230×200mmWeight: 7kgPacking List:1 x Host1 x Welding Pen1 x Foot Switch1 x Needle Grinding Machine1 x Six-Section Fixture4 x Brazing Pins100 x Nickel Sheet2 x Insurance Tube1 x Hex Wrench1 x Warranty Card1 x ManualNotice:1. Please keep the surface of the soldering pin clean and wipe off the oxide with sandpaper.2. Set the pressure regulator to the correct value to avoid unsatisfactory welding results.2. Please do not use the power strip, use the power socket to ensure stable power supply, otherwise it may cause triggering.We insist on providing you with satisfactory products. If you have any questions during use, please contact me in time!

• [LED Lighting Function]-Spot welding needle welding LED lamp lighting device, which can enhance the sight of spot welding at night or in low-brightness environments, and spot welding accurately.
• [Fixed Pulse Spot Welding]-The fixed pulse spot welding head can achieve precise fixed welding, which greatly improves the welding efficiency.
• [Ergonomics Principle]-The handheld pulse spot welding pen adopts the ergonomics concept, and the appearance is slim and easy to hold, which provides maximum convenience for users.
• [Foot Welding]-The spot welder is equipped with a foot control interface and a foot switch to make welding more accurate and reliable. The welding pressure regulator can continuously adjust the welding needle pressure from 300g to 700g, which is convenient for welding workpieces with different thicknesses.
• [Wide Scope of Application]-Suitable for various sizes of battery packs, button batteries, polymer batteries and protective plates, mobile phone cameras, stainless steel hardware, and stainless steel meshes.
